Description
Quick heads-up.
- Verify local prefab setup codes — base anchors, pad stability, and wind/snow load.
- This unit ships dry (no water or electrical pre-install); power and plumbing are optional add-ons.
- Prepare a level base — deploys hydraulically in under an hour.
Why people pick this model
The Expandable House 0208-13FT is a smaller, transport-friendly prefab built for fast setup and solid durability. With a Q235 steel frame, EPS-composite fire-rated panels, and double-glazed aluminum windows, it’s ideal for quick-deploy projects that still need insulation, soundproofing, and weather protection.
It’s frequently used as a site office, tiny home shell, or modular workspace, giving you structural strength without the complexity of plumbing or electrical work out of the box.
Highlights
- Compact footprint – easy to ship and unfold anywhere.
- Steel structure – Q235 frame and zinc-rich coating for corrosion resistance.
- Thermal panels – B2 fireproof EPS walls (50 mm) and roof (40 mm).
- Insulated openings – tempered glass doors and casement windows.
- Anti-slip flooring – 15 mm Eco-board + 3 mm vinyl leather.
- Dry-shell ready – bring your own systems or keep it minimalist.
Good for
Temporary living • Field office • Mobile studio • Storage • Remote work cabin
Core Specs (quick view)
- Unfolded Size (L×W×H): 3910 × 5340 × 2510 mm → 12 ft 10 in × 17 ft 6 in × 8 ft 3 in
- Folded Size: 3910 × 990 × 2570 mm → 12 ft 10 in × 3 ft 3 in × 8 ft 5 in
- Weight: 1970 kg (≈ 4 340 lb)
- Pack-out: 6 sets / 40 HC container
- Frame / Roof: Q235 steel frame / steel plate roof / zinc-rich powder finish
- Walls / Roofboard: Fireproof B2 EPS foam composite (50 mm walls / 40 mm roof)
- Floor: 15 mm Eco-board + 3 mm anti-slip wear-resistant floor leather
- Doors & Windows: Broken-bridge aluminum single door + tempered glass windows
- Utilities: No pre-fit plumbing or power (ready for user install)
- Fire Resistance: A1 / B2 (optional)
Plan for (before delivery)
- Pad / anchors: Level slab or steel pad per local load standards.
- Power: Optional connection kit (110 V–240 V).
- Water / Drain: Stub-in after delivery if desired.
- Upgrades: Lighting kit, solar input, HVAC split, or utility hub.
Full Specifications (table)
| Category | Standard / Details |
| Product Name | Expandable House 0208-13FT (Mobile House) |
| Unfolded Size | L3910 × W5340 × H2510 mm (13 × 17.5 × 8 ft) |
| Folded Size | L3910 × W990 × H2570 mm (13 × 3 × 8.4 ft) |
| Packing per Container | 6 sets / 40 HC |
| Weight | 1970 kg (≈ 4 340 lb) |
| Main Part | Q235 steel frame / steel plate roof / zinc-rich bottom plastic + gray powder coat |
| Wallboard | Fireproof B2 EPS foam composite 50 mm |
| Roofboard | Fireproof B2 EPS foam composite 40 mm |
| Floor | 15 mm Eco-board + 3 mm anti-slip wear-resistant leather |
| Doors & Windows | Broken-bridge aluminum exterior casement windows + tempered glass door |
| Bathroom / Furniture / Water / Power | None (pre-install excluded) |
| Attachment | Canopy / Treads / Adjustable base |
| Fire Resistance | A1 / B2 (optional) |
Configuration Details
| Item | Specification |
| Product Model | Universal No Water or Electricity – 002-08-003A-TY |
| Air Spring | 3500 N |
| Winch | 1200 lbs |
| Steel Wire Rope | Φ6 mm |
| Broken-Bridge Aluminum Single Door | W1000 × H1990 mm, double-layer hollow tempered glass (with lattice trim) |
| Broken-Bridge Aluminum Outward-Opening Window | W650 × H1180 mm (outward-opening casement type) |
| Step | Steel step + non-slip mat |
| Eave | Steel eave |
Features at a Glance
Modern Design • High Quality • Fully Finished Prefab Shell • Easy Installation • Removable • Heat Insulation • Soundproof • Shock Resistance • Durable • Comfortable
